Product Description
PGC 4000v2 Power Generation Controller
The PGC 4000v2 is an intelligent, integrated Power Generation Controller operating with our Series 2400 Paralleling Switchgear.
- Run Time Configurable programming allows integration with multiple gen set manufacturers
- PGC 4000 v2 Technology: 1Gbps LAN Network Speed Capability, PC Based Peripherals for Service Support (USB/ETHERNET), Windows 7 Compliant
- Integrated, Revenue Grade, Utility and Generator Metering with Power Quality Measurement
- Digital Engine-Generator Controls
- Digital Auto Synchronizing & kW/kVAR Load Sharing
- 17” Color Touch Screen Operator Display with Run-time Configurable Graphics.
- Digital Protective Relaying for Generator & Utility Supply per IEEE & ANSI standards
- High Speed/Noise Immune Ethernet-based Communications
- Compliant with IEEE 1547 Distributed Generation Interconnect Standard
- Certified to UL 508A.
Features
| Power Supply: | 10 - 35 Vdc |
| Temperature Range: | -5 to 50 °C |
| Environmental Rating: | Nema 1 |
| Communication: | Ethernet 10BaseT |
| Safety / Performance Standards: | UL 508, CSA C22.2 #14 Industrial Control Equipment Certification, ANSI C12.20 Class 0.2 Metering Accuracy, IEEE C37.90.2, IEEE Trial-Use Standard on Withstand Capability of Relay Systems to Radiated Electromagnetic Interference from Transceivers |
- Industry Leading Technology (1Gbps LAN Network Speed Capability
- 10-15 Times More Processing Power = Future Feature Expansion Capability
- PC Based Peripherals for Easier Service Support (USB/ETHERNET
- 32 Digital Inputs (Includes 8 New Inputs on PGC 4000v2
- 24 Digital Relay Outputs (Includes 8 New Outputs on PGC 4000v2
